Genuine Miller Industries part no. 09021896: 812 CROSSBAR ASSEMBLY.
- Manufacturer part number: 09021896
- Source: part number confirmed by Miller Industries parts department (2025-09-18)
Parts included
These are the parts that make up this assembly. Quantities are per assembly. Part numbers that we carry link to those products.
| Ref | Part Number | Description | Qty |
|---|---|---|---|
| 1 | 0300113 | GREASE FITTING, 1/4-28 STR | 1 |
| 2 | 0301959 | SNAP RING-INTERNAL 1-1/2" | 2 |
| 3 | 03023670 | ELBOW, 4MJ-6FJX90 | 2 |
| 4 | 03023790 | HOSE, 76" 6MJ-4M3K-4FJX | 2 |
| 5 | 0311600 | CYL, 812 CLAW GEN3, PUSH STYLE | 2 |
| 6 | 0311617 | FITTING - 6MJ-BLKHD-TEE | 2 |
| 7 | 0311657 | HOSE - 4FJX-4M3K-MTF-6FJX x 28 | 2 |
| 8 | 0311658 | HOSE-4FJX-4M3K-MTF-6FJXx37-1/2 | 2 |
| 9 | 0311739 | STOP PAD CLAW GEN3 CBAR | 2 |
| 10 | 0400079 | SCREW, 1/4-20X3/4 FHS GR5 | 20 |
| 11 | 0400121 | SCREW, 3/8-16X3/4 HHC GR5 | 8 |
| 12 | 0400428 | NUT, 5/8-11 LOK FLEX JAM | 2 |
| 13 | 0400480 | WASHER, 3/8 | 4 |
| 14 | 0400482 | LKWASHER, 3/8 | 8 |
| 15 | 0400992 | SCREW, 1/2-20X2-1/2 FHS BO | 2 |
| 16 | 0401008 | SCREW, 5/8-11X5 FHS | 2 |
| 17 | 0401150 | SNAP RING, 3/4 INT | 2 |
| 18 | 0710092 | WASHER, THRUST 6500 W/L | 2 |
| 19 | 0730174 | PIN - C'BAR PIVOT - GEN 3 CBAR | 1 |
| 20 | 0730175 | PLATE - PIVOT PIN KEEPER - GEN 3 | 1 |
| 21 | 0730180 | PIN - CLAW PIVOT - GEN 3 CBAR | 2 |
| 22 | 0730181 | PIN - CLAW CYL. - BASE - GEN 3 | 2 |
| 23 | 0730183 | PLATE - ACCESS COVER - GEN 3 | 4 |
| 24 | 0730258 | PLT, END CAP LH | 1 |
| 25 | 0730259 | PLT, END CAP RH | 1 |
| 26 | 0811029 | WHEEL SPACER WLMT 812 | 2 |
| 27 | 0811056 | 812 GEN3 CROSSBAR WLMT | 1 |
| 28 | 0811061 | PIN WLMT, CLAW/CYL GEN3 | 2 |
| 29 | 0911417 | DETENT ASSY - GEN 3 CROSSBAR | 1 |
| 30 | 0911467 | 812 CLAW ASSY GEN3.2 CROSSBAR | 2 |
| 31 | HC1291 | FITTING, 4MJ-4MB STR THR | 4 |
| 32 | HD0160 | SNAP RING, 3/4 EXTERNAL | 2 |
09021896 is listed at the top of this manual page with no reference number, so every part on the page is included. Source: Vulcan 800 Series Low-Profile (Models 801-812) Parts Manual, Form No. 05003264 (May 2022), page 11. The list has 32 parts. Ref numbers match the diagram below.
Manual diagram
09021896 CROSSBAR ASSEMBLY, ENCLOSED. You can also view this assembly with live prices and Quick Add on the Vulcan 800 Series Low-Profile (Models 801-812) Parts Manual parts page.
