Vulcan V-30 Gen 2 Sheave Assembly - 3014 – OEM Part No. 3014-931000
Genuine replacement Sheave Assembly - 3014 (part no. 3014-931000) for the Vulcan V-30 Gen 2 (2022 manual), manufactured by Miller Industries Towing Equipment Inc.
| Manufacturer part number | 3014-931000 |
|---|---|
| Manual description | SHEAVE ASSEMBLY - 3014 |
| Fits | Vulcan V-30 Gen 2 (2022 manual) |
| Assembly | 0911730, 3212/V30 Long Tower Boom Assembly |
| Diagram reference (item) no. | 34 |
| Quantity used per assembly | 2 |
| Source | Vulcan V-30 Gen 2 Parts Manual, Form No. 05004627 (August 2022) |
Parts included
These are the parts that make up this assembly. Quantities are per assembly. Part numbers that we carry link to those products.
| Ref | Part Number | Description | Qty |
|---|---|---|---|
| 1 | 0300113 | GREASE FITTING, 1/4-28 STR | 1 |
| 2 | 0300626 | SHEAVE, 8" 58SHVBBAY 1.5 | 1 |
| 3 | 0400147 | SCREW, 3/8-24 X 5/8 HHC GR5 | 1 |
| 4 | 0400184 | SCREW, 1/2-13 X 2-1/4 HHC GR8 | 1 |
| 5 | 0400408 | NUT, 1/2-13 LOK | 1 |
| 6 | 0400482 | LKWASHER, 3/8 | 1 |
| 7 | 3014-802000 | SHEAVE PIN WLMT. | 1 |
| 8 | 3014-831000 | SHEAVE WELD'T - 3014 | 1 |
| 9 | 3014-831100 | GUIDE - SWIVEL | 1 |
3014-931000 is listed at the top of this manual page with no reference number, so every part on the page is included. Source: Vulcan V-30 Gen 2 Parts Manual, Form No. 05004627 (August 2022), page 27. The list has 9 parts. Ref numbers match the diagram below.
Manual diagram
3014-931000, SHEAVE ASSEMBLY. You can also view this assembly with live prices and Quick Add on the Vulcan V-30 Gen 2 Parts Manual parts page.
