S10 G2 INBOARD OFFSET OIL TANK - 09003530

$949.20
SKU:
09003530
Condition:
New

S10 G2 INBOARD OFFSET OIL TANK

Miller Industries part number 09003530.

Parts included

These are the parts that make up this assembly. Quantities are per assembly. Part numbers that we carry link to those products.

Ref Part Number Description Qty
108003114SERIES 10 G2 IBT OFFSET OIL TANK - 12 GAL1
203006085#8 O-RING PLUG1
377C00STRAIGHT SUCTION HOSE FITTING 20 x 201
40752557-375IB OIL TANK SHIM - 3/8 (DODGE ONLY)2
576270IN-TANK FILTER ASSEMBLY #16 SAE PORT1
76271REPLACEMENT FILTER ELEMENT1
60402118LOCK WASHER 5/16 SS2
704001427BOLT SHCS 5/16-18 UNC x 7/8 SS2
876213FILLER BREATHER CAP1
90301368ADAPTOR 202702 - 16 x 121

09003530 is listed at the top of this manual page with no reference number, so every part on the page is included. Source: Vulcan Series 10 Gen II Aluminum & Steel Carriers Parts Manual • PN. 0540040 • REV. 08/2025, page 33. The list has 10 parts. This uses the 2025 parts list (0402118 stainless 5/16 lock washer). Ref numbers match the diagram below.

Manual diagram

Miller Industries 2017 FORD F550 - DODGE 5500 12 GAL. OIL RESERVOIR GROUP - 09003530 exploded diagram, showing all 10 parts. From Vulcan Series 10 Gen II Aluminum & Steel Carriers Parts Manual • PN. 0540040 • REV. 08/2025, page 33.

2017 FORD F550 - DODGE 5500 12 GAL. OIL RESERVOIR GROUP - 09003530. You can also view this assembly with live prices and Quick Add on the Vulcan Series 10 Gen II Aluminum & Steel Carriers Parts Manual parts page.
