Century 4024/T2 Pan-Valve Assembly – OEM Part No. 0903536
Genuine replacement Pan-Valve Assembly (part no. 0903536) for the Century 4024 / T2, manufactured by Miller Industries Towing Equipment Inc.
| Manufacturer part number | 0903536 |
|---|---|
| Manual description | PAN-VALVE ASSY |
| Fits | Century 4024 / T2 |
| Assembly | Subframe Assembly (0907320); Pan-Valve Assembly (0903536) |
| Diagram reference (item) no. | 22 (Subframe Assembly (0907320)); -- (Pan-Valve Assembly (0903536)) |
| Quantity used per assembly | 1 (Subframe Assembly (0907320)); (Pan-Valve Assembly (0903536)) |
| Source | Century 4024 / T2 Parts Manual, Form No. 05006247 (Rev. 02/2025) |
Parts diagrams:
Parts included
These are the parts that make up this assembly. Quantities are per assembly. Part numbers that we carry link to those products.
| Ref | Part Number | Description | Qty |
|---|---|---|---|
| 1 | 0300044 | ADAPTER, 6MJ-8MB | 2 |
| 2 | 0301470 | FITTING, 90ELB 6MJ-8MB90 | 2 |
| 3 | 0301730 | VALVE, DOUBLE HOLDING | 1 |
| 4 | 0400078 | SCREW, 1/4-20X2 HHC GR5 | 2 |
| 5 | 0400126 | SCREW, 3/8-16X1 HHC GR5 | 2 |
| 6 | 0400135 | SCREW, 3/8-16X4-1/2 HHC GR5 | 6 |
| 7 | 0400367 | NUT, 1/4-20 LOK | 2 |
| 8 | 0400392 | NUT, 3/8-16 LOK | 8 |
| 9 | 0400451 | WASHER, 1/4 | 4 |
| 10 | 0704045 | SPACER, CONTROL VALVE | 6 |
| 11 | 0717827 | PLATE, VALVE MOUNTING | 1 |
| 12 | 0719122 | PLATE - VALVE MTG | 1 |
| 13 | 0906494 | VALVE ASSY,PARKER 4 SPL W/FTGS | 1 |
| 14 | 0906495 | VALVE ASSY,PARKER 5 SPL W/FTGS | 1 |
0903536 is listed at the top of this manual page with no reference number, so every part on the page is included. Source: Century 4024 / T2 Parts Manual, Form No. 05006247 (Rev. 02/2025), page 61. The list has 14 parts. Ref numbers match the diagram below.
Manual diagram
PAN-VALVE ASSEMBLY (0903536). You can also view this assembly with live prices and Quick Add on the Century 4024 / T2 Parts Manual parts page.
