ADJUSTABLE CAB PROTECTOR
Miller Industries part number 09008330-XX.
Parts included
These are the parts that make up this assembly. Quantities are per assembly. Part numbers that we carry link to those products.
| Ref | Part Number | Description | Qty |
|---|---|---|---|
| 1 | 07011335-46 | CAB PROTECTOR TRIM CHANNEL | 1 |
| 2 | 08017569 | ADJUSTABLE CAB PROTECTOR BASE | 1 |
| 3 | 08007570 | CAB PROTECTOR CENTER SUPPORT | 1 |
| 4 | 08007571 | ADJUSTABLE SIDE TUBE | 2 |
| 5 | 0400176 | BOLT HHCS 1/2-13 UNC x GR5 | 8 |
| 6 | 0400491 | LOCK WASHER 1/2-ZP | 8 |
| 7 | 0403128 | FLAT WASHER 1/2-ZP | 8 |
| 8 | 0400126 | BOLT HHCS 3/8-16 UNC x 1 GR5 | 6 |
| 9 | 0400480 | FLAT WASHER 3/8 ZP | 6 |
| 10 | 04002907 | NUT, FLANGED NYLOK 3/8-16 UNC ZP | 6 |
09008330-XX is listed at the top of this manual page with no reference number, so every part on the page is included. Source: Vulcan Series 10 Gen II Aluminum & Steel Carriers Parts Manual • PN. 0540040 • REV. 01/2022, page 72. The list has 10 parts. Ref numbers match the diagram below.
Manual diagram
ADJUSTABLE CAB PROTECTOR 09008330-XX (BED MOUNTED). You can also view this assembly with live prices and Quick Add on the Vulcan Series 10 Gen II Aluminum & Steel Carriers Parts Manual parts page.
