33" TOOLBOX- ALUM W/ SS DOOR - 377000

$1,470.80
SKU:
377000
Condition:
New

33" TOOLBOX- ALUM W/ SS DOOR

Miller Industries part number 377000.

Parts included

NOTE: 377000 DOES NOT INCLUDE MOUNTING BRACKETS

Items 8 and 9 (37855L and 37855R tank and toolbox mounting brackets) are shown on the manual page for ordering and are not included with the assembly as sold. Item 7 (37760 tandem box spacer channel) is optional.

These are the parts that make up this assembly. Quantities are per assembly. Part numbers that we carry link to those products.

Ref Part Number Description Qty
154658ROTARY PADDLE LATCH1
-54657GASKET FOR PADDLE LATCH1
-81111#8-32 x 1/2 STAINLESS ONE WAY SCREW4
-83111#8-32 STAINLESS KEPT NUT4
2376182STRIKER PIN MOUNTING PLATE1
-54659STRIKER PIN1
-0403072STAINLESS CARRIAGE BOLT 5/16-18 x 3/42
-0400465FLAT WASHER 5/164
-0400464LOCK WASHER 5/162
-83110NUT 5/16-182
-83125NYLON LOCK NUT 5/16-181
3377100WBOX WELDMENT1
437740DOOR ASSEMBLY1
-37741DOOR WELDMENT1
-81100STAINLESS CARRIAGE BOLT 1/4-20 x 3/46
-83105NYLON LOCK NUT 1/4-206
537744DOOR REINFORCEMENT1
637735HINGE1
-811014SS SOCKET BUTTON HEAD BOLT 1/4-20 x 7/82
-811012SS SOCKET BUTTON HEAD BOLT 1/4-20 x 3/43
-811010SS SOCKET BUTTON HEAD BOLT 1/4-20 x 5/85
-83105NYLON LOCK NUT 1/4-2010
737760TANDEM BOX SPACER CHANNEL (OPTIONAL)1
837855LTANK AND TOOLBOX MTG BRACKET-LH1
937855RTANK AND TOOLBOX MTG BRACKET-RH1
105A221LANYARD-21 INCH2
1137770SHELF1
1203002300TOOLBOX MAT 33"1
1318151STRIM SEAL - 3/8 WITH 5/8 BULB - 96 IN.8 FT

377000 is listed at the top of this manual page with no reference number, so every part on the page is included. Source: Century Series 10 VLA, Form 05006107, Rev 10/2026, printed page 60. The list has 29 parts. Items 8 and 9 (37855L and 37855R tank and toolbox mounting brackets) are shown on the manual page for ordering and are not included with the assembly as sold. Item 7 (37760 tandem box spacer channel) is optional. Ref numbers match the diagram below.

Manual diagram

Miller Industries 33 inch Aluminum Toolbox (377000) exploded diagram, showing the parts of this assembly. From Century Series 10 VLA, Form 05006107, Rev 10/2026, printed page 60.

33 inch Aluminum Toolbox (377000).
